Tech Ops Hub | FOH Manual

Power Management

Automated scheduling and staged sequencing via Kasa and Furman hardware.

Weekly Schedule

Sunday Morning 07:00 ON

Sunday Afternoon 14:00 OFF

Wednesday Night 17:30 - 20:30

Manual Override

If automation fails, use the Kasa power strip in the sound booth. Toggle the outlet closest to the USB ports.

Note: PS-REL Relay triggers the CN-1800S

Staged Sequencing Logic (30s Intervals)

graph TD Start[Kasa Strip Toggle] -->|Signal| Relay[PS-REL Relay] Relay -->|Trigger| Seq[Furman CN-1800S] subgraph "Sequence Loop" Seq --> S1[Stage 1: Speakers & Subs] S1 --> S2[Stage 2: Rack Amps] S2 --> S3[Stage 3: Console & FOH Power] end style S1 fill:#f0f9ff,stroke:#0369a1 style S2 fill:#f0f9ff,stroke:#0369a1 style S3 fill:#ecfdf5,stroke:#047857,stroke-width:2px

Audio Architecture

Core I/O and routing for the Allen & Heath SQ-5 ecosystem.

Sound Booth

SQ-5 Console (SLink)
4x Shure Wireless
1x Sennheiser (Orange)
1x Pastor Bodypack

Sound Closet

AB168 Digital Snake
DBX DriveRack
Passive Aux Amps

Stage I/O

7-Mic Drum Array
Nord Grand Piano
Neumann KMS-105
Multitracks iPad

Signal Routing Topology

graph LR subgraph "Inputs" Snake[Digital Snake] Splice[Analog Splice Box] Wireless[Wireless Local] end Snake --> SQ5[SQ-5 Hub] Splice --> SQ5 Wireless --> SQ5 subgraph "Outputs" SQ5 --> FOH[Main L/R] SQ5 --> IEM[Wireless IEM] SQ5 --> Stage[Monitor Wedges] SQ5 --> Split[SLink to Broadcast] end style SQ5 fill:#fef9c3,stroke:#a16207,stroke-width:2px

Visuals & ProPresenter

Display Matrix

Output 1: Audience Dual BenQ Projectors (HDMI Split)

Output 2: Stage BenQ Projector (Confidence Monitor)

Output 3: Management Primary Control Monitor

Output 4: Stream HDMI to SDI (Lower Third Overlay)

Livestream & Broadcast

Managing the relationship between FOH and the Livestream room.

⚠️ Technical Dependency

The Qu-32 receives signals Post-Preamp. This means the Analog Gain set on the SQ-5 is the only thing that will alter the Qu-32 levels. Any fader moves or EQ on the SQ-5 do NOT affect the stream.
